ZH-S101單節氣缸手持式螺絲機Hand-held Screw Machine
功能特點Functions and characteristics
1.螺絲范圍Screw range：M2-M5。
2.用的螺絲頭花型如：一字、十字、三角、梅花、內六角、H頭等。Screw head pattern for use, such as: word, cross, triangle, plum, hexagon, H head, etc.
3.用的螺絲材料如：鐵、銅、不銹鋼等。Screw materials such as iron, copper, stainless steel, etc.
4.螺絲產品的材料如：塑膠、鐵、鋁等。Materials of screw products, such as plastic, iron, aluminum, etc.
5.效率高,省成本: 鎖付速率可達到0.5秒1顆螺絲,比傳統擰緊效率提高1倍.省1個人。. High efficiency, cost saving: The locking rate can reach 1 screw for 0.5 seconds, which is 1 times higher than the traditional tightening efficiency. Can save 1 man laborer.
6.更輕松,更質保: 左手無需取螺絲，可用于扶住產品；且可保持垂直鎖付,確保鎖付質量。 More relaxed, more quality assurance: The left hand does not need to take the screw, can be used to hold the product; and can maintain vertical lock pay, to ensure the quality of the lock.
7.更清潔,更環保:不再直接接觸螺絲，避免手部接觸造成二次污染而生銹Cleaner, more environmentally friendly: no longer in direct contact with the screws, avoid contact with the hands causing secondary pollution and rust.
產品規格Product specification
型號Model | ZH-S101單節氣缸手持式螺絲機Hand-held screw machine | ZH-S201雙節氣缸手持式螺絲機Double-section Cylinder Hand-held Screw Machine |
功率Power | 30W | 100W |
輸送距離Delivery Distance | 1-4米1-4 meters | 0.5-2米0.5-2 meters |
供料容量Feed Capacity | 標準螺絲3000個Standard screws 3000 | 標準螺絲2000個Standard screws 2000 |
主要適用的螺絲孔Main screw hole | 沉孔 | 平面Plane hole position |
工作氣壓Working Pressure | 4-6KGF/Cm2 | |
電源Power supply | 220V，50-60HZ | |
使用環境Use Environment | -20-40°C | |
批頭選型Batch Selection | 滑套式、根據產品定Sleeve type, bracket type(According to product specification) | |
電批選型Electric Batch Type | 標準臺灣奇力速電批 可按客戶要求Standard batch from Taiwan KILEWS(According to customer requirements) | |
螺絲規格Screw Specifications | 一字、十字、梅花、內六角、三角、工字型Word, cross, plum, hexagon, triangle, I-shaped | |
適用行業Applicable Industry | 通用性強Versatility, basically covers all products | |
設備兼容Equipment Compatible | 公差0.5MM、長度5MM Tolerance 0.5MM, length 5MM | |
外形尺寸Dimensions | 360*250*195MM | |
儀器售后政策：
*儀器保修期：一年
*售后電話：4008166687
我們提供部分設備的遠程安裝與調試，提供上門安裝維修服務，但收取一定的服務費；有基礎的我公司將免費提供技術指導，由需方調試安裝。
